Slide Arm Cushion Stop for TS11205

Slide Arm Cushion Stop for TS11205

Product Code: 11136

The 11136 Cushion Stop is a high-density replacement foam strip designed specifically for the TS11205 Slide Arm Door Closer rail. This essential component acts as a mechanical buffer, providing a "soft stop" to the door's opening swing to protect the door, closer arm, and surrounding walls from impact damage.

Key Features

• Impact Absorption: High-density foam construction specifically engineered to dissipate force at the end of the opening cycle.
• Simple Retrofit: Fits directly and securely into the slide rail channel of the TS11205.
• Wall Protection: Provides a mechanical backcheck-style cushioning effect, ideal for areas where floor stops cannot be installed.
• Hardware Longevity: Reduces mechanical stress on the closer shuttle and arm assembly by preventing metal-on-metal impact.
• Discreet Design: Sits entirely within the slide rail for a clean, architectural finish.

Technical Specification

• Material: High-grade polymer foam / Rubberized cushion
• Compatibility: Designed exclusively for Rutland TS11205 series slide rails
• Function: Mechanical backcheck buffer
• Environment: Performance stable between -30°C and +60°C
• Durability: Tested for high-frequency commercial environments

Application Note

The 11136 foam strip should be positioned within the slide rail adjacent to the rail end cap. During operation, the shuttle (3) makes contact with this cushion to safely limit the door's opening travel.
